Digital Product Lithium Lipo Batteries LP-523450-1S-3 3.7v 950mAh Li-ion Polymer Battery Pack
| Place of Origin | Guangdong, China |
|---|---|
| Brand Name | BAKTH |
| Model Number | LP-523450-1S-3 |
| Minimum Order Quantity | 2 pieces |
| Price | CN¥17.67/pieces 2-999 pieces |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Battery Size | LP-523450-1S-3 3.7v 950mAh | Battery Type | Solid State |
|---|---|---|---|
| Cycle Life | 300 Cycles | Cathode Materials | LiCoO2 |
| Application | Toys, Power Tools, Home Appliances | Weight | About 28g |
| Operating Temperature(℃) | -20~60℃ | Type | Li-Ion |
| Size | About 5.5*34.5*51(mm) | Max Charge Voltage | 4.2V |
| Discharge Cut Off Voltage | 2.75V | Standard Charge Current | 0.2C |
| Max Charge Current | 1C | Charging Mode | CC/CV |
| Charging Temperature | 0~45℃ | Discharging Temperature | -20 ~ 60℃ |
| Warranty | 12 Months | ||
| Highlight | 3.7v li polymer battery pack,950mah li polymer battery pack |
||
Product Description
Digital Product Lithium Lipo Batteries LP-523450-1S-3 3.7v 950mAh Li-ion Polymer Battery Pack
Product Specifications
| Attribute | Value |
|---|---|
| Battery Size | LP-523450-1S-3 3.7v 950mAh |
| Battery Type | Solid state |
| Cycle Life | 300 cycles |
| Cathode Materials | LiCoO2 |
| Application | Toys, Power Tools, Home Appliances |
| Weight | About 28g |
| Operating Temperature(℃) | -20~60℃ |
| Type | Li-Ion |
| Size | about 5.5*34.5*51(mm) |
| Max charge voltage | 4.2V |
| Discharge cut off voltage | 2.75V |
| Standard charge current | 0.2C |
| Max charge current | 1C |
| Charging mode | CC/CV |
| Charging Temperature | 0~45℃ |
| Discharging Temperature | -20 ~ 60℃ |
| Warranty | 12 Months |
Technical Features
Nominal capacity
950mAh
Nominal voltage
3.7V
Max charge voltage
4.2V
Discharge cut off voltage
2.75V
Standard charge current
0.2C
Max charge current
1C
Standard discharge current
0.2C
Max discharge current
1C
Charging mode
CC/CV
Internal resistance
≤180
Cycle life
300 cycles
Rechargeable
Yes
Charging Temperature
0~45℃
Discharging Temperature
-20 ~ 60℃
Storage temperature
≤1 month: 45~60℃
≤3 months: 25~45℃
≤12 months: -20~25℃
≤60%RH Recharge every 6 months
≤3 months: 25~45℃
≤12 months: -20~25℃
≤60%RH Recharge every 6 months
Humidity Range
0~85% (non-condensing)
Dimension
about 5.5*34.5*51(mm)
Weight
about 28g
Brand
BAKTH / Neutral / OEM
Warranty
12 Months
PCB/PCM
yes
Connector
3P connector
Battery type
Li-ion
