2.22Wh Polymer Lithium Battery 3.7 V 60025P600A 502648P 1S1P 600mAh
| Place of Origin | Guangdong, China |
|---|---|
| Brand Name | BAKTH/OEM |
| Model Number | LP-502648-1S-3M, 60025P600A |
| Minimum Order Quantity | 3 pieces |
| Price | CN¥43.26/pieces 3-20 pieces |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Battery Size | 502648P, BAKTH-502648P-1S-3 | Battery Type | Solid State |
|---|---|---|---|
| Cycle Life | 300 Cycles | Cathode Materials | LiCoO2 |
| Application | Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, Electric Vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric For | Weight | About 14g |
| Operating Temperature(℃) | -20~60℃ | Product Name | 1S1P 3.7V 600mAh 2.22Wh Lithium Ion Polymer Cell 502648P |
| Dimension | About 6.0*26.5*51(mm) | Warranty | 12 Months |
| Max Charge Current | 1C | Charging Mode | CC/CV |
| Charging Temperature | 0~45℃ | Discharging Temperature | -20 ~ 60℃ |
| Keywords | 3.7v Lithium Ion Battery | ||
| Highlight | 2.22Wh Polymer Lithium Battery,2.22Wh lithium ion polymer power bank,502648P Polymer Lithium Battery |
||
Product Description
2.22Wh Polymer Lithium Battery 3.7 V 60025P600A 502648P 1S1P 600mAh
Product Specifications
| Attribute | Value |
|---|---|
| Battery Size | 502648P, BAKTH-502648P-1S-3 |
| Battery Type | Solid state |
| Cycle Life | 300 cycles |
| Cathode Materials | LiCoO2 |
| Application | Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies |
| Weight | About 14g |
| Operating Temperature | -20~60℃ |
| Dimension | About 6.0*26.5*51(mm) |
| Warranty | 12 Months |
| Max charge current | 1C |
| Charging mode | CC/CV |
Technical Parameters
Nominal Capacity
600mAh
Max Charge Voltage
4.2V
Discharge Cut Off Voltage
2.75V
Standard Discharge Current
0.2C
Max Discharge Current
3C
Internal Resistance
≤180
Humidity Range
0~85% (non-condensing)
Brand
BAKTH /Neutral /OEM
PCB/PCM
yes
Connector
3P connector
Applications
Smart wearable devices, smart cards, smart electronics, earphone, power bank, MPS, Tablet PC, laptop, GPS, medical devices, electric children toys, electric shoes, electric blanket, intelligent door lock, intelligent lighting, emergency light, industrial cameras.
Our Customization Services
Customized battery voltage, capacity size and case
Customized connect plug and socket, Cable, waterproof
Customized special battery packs for any applications
Customized BMS charging and discharging current, balance function with communication protocol
Product Advantages
- High energy density - potential for yet higher capacities
- Does not need prolonged priming when new - one regular charge is all that's needed
- Relatively low self-discharge - less than half that of nickel-based batteries
- Low Maintenance - no periodic discharge needed; no memory effect
- Specialty cells can provide very high current to applications such as power tools
Safety Features
Passed rigorous safety tests including drop shock, impact, squeeze, soak, bonfire, over-charge, and over-discharge. No leakage, no venting, no disassembly, no rupture and no fire with stable chemical structure.
