BAKTH-875870P-2S-3, 7.4V, 4520 mAh, 33.45Wh
| Place of Origin | China |
|---|---|
| Brand Name | BAKTH |
| Certification | UN38.3 |
| Model Number | BAKTH-875870P-2S-3 |
| Minimum Order Quantity | 2PCS |
| Price | US$21.65 |
| Packaging Details | Carton |
| Delivery Time | 15~20days |
| Payment Terms | T/T |
| Supply Ability | 100000PCS/Month |
Product Details
| Voltage | 7.4V | Discharging Temp | -20℃~45℃ |
|---|---|---|---|
| Charge Current | 1C | Chemistry | Li-pol |
| Chargeable | Yes | Working Temperature | 0℃ ~45℃ |
| Capacity | 4520mAh | ||
| Highlight | 7.4V Li Polymer battery pack,4520 mAh rechargeable battery,33.45Wh high capacity battery |
||
Product Description
Product Overview:
The BAKTH-875870P-2S-3 is a 7.4V lithium-ion battery pack configured in a 2S arrangement (two cells in series), delivering a nominal voltage commonly used in RC vehicles, portable power tools, and mid-power electronics. With a capacity of 4520mAh and energy content of 33.45Wh, it offers a balanced combination of runtime and compact design. The pack supports moderate to high discharge rates, typically ranging from 1C to 3C (4.5A–13.5A continuous), making it suitable for applications requiring sustained power output without excessive heat generation.
Description:
|
|||||||||||||||||||||||||||||||
2. Physical & Safety Features
Constructed in a prismatic or pouch format (dimensions inferred as ~87mm × 58mm × 7.0mm based on model coding), the pack integrates a Protection Circuit Module (PCM) for overcharge, over-discharge, short-circuit, and overcurrent protection. Its lightweight design (~120g) and robust casing ensure durability in mobile or vibration-prone environments. Standard connectors (e.g., JST-XH, Molex) provide secure, low-resistance connections.
3. Typical Applications
- RC Models: Drones, hobby cars, and aircraft requiring 2S power
- Portable Electronics: Handheld scanners, diagnostic devices, and portable audio equipment
- Backup Power: Emergency lighting, IoT devices, and small UPS systems
- DIY Projects: Robotics, custom power banks, and experimental setups
4. Charging & Maintenance Guidelines
- Charging: Use a balanced Li-ion charger set to 8.4V (4.2V per cell) with CC/CV mode. Recommended charge current: 0.5C–1C (2.26A–4.52A).
- Discharge Cutoff: Avoid discharging below 6.0V (3.0V per cell) to prevent cell damage.
- Storage: Store at 3.7V–3.8V per cell (7.4V–7.6V total) in a cool, dry environment (10°C–25°C).
- Cycle Life: 300–500 cycles at 80% depth of discharge under normal operating conditions.
