25.6V 20Ah LiFePO4 Battery Pack 32700 8S4P Long Cycle Life BAKTH ZY-ED-3-E0359 with Smart BMS
| Place of Origin | Guangdong, China |
|---|---|
| Brand Name | BAKTH |
| Certification | CE, RoHS, UN38.3, MSDS |
| Model Number | ZY-ED-3-E0359 (60002218A) |
| Minimum Order Quantity | 1 Piece |
| Price | USD 180-260/Piece (FOB Shenzhen) |
| Packaging Details | Standard export carton with foam protection |
| Delivery Time | 15-25 Days |
| Payment Terms | T/T,L/C,Western Union |
| Supply Ability | 5000 Pieces/Month |
Product Details
| Cell Type | 32700 LiFePO4 (3.2V) | Configuration | 8S4P (32 Cells) |
|---|---|---|---|
| Nominal Voltage | 25.6V | Nominal Capacity | 20Ah |
| Energy | 512Wh | Cycle Life | 4000+ Cycles |
| BMS | Built-in Smart BMS | Charging Voltage | 29.2V |
| Discharge Cut-off | 20.0V | Max Continuous Discharge Current | 40A |
| Communication | RS485 / CAN (Optional) | Operating Temperature | -20 To 60 Deg C |
| Warranty | 5 Years | ||
| Highlight | Long Cycle Life LiFePO4 Battery Pack,Custom 25.6V 32700 8S4P Battery Pack,Smart BMS Protected LiFePO4 Battery |
||
Product Description
25.6V 20Ah LiFePO4 Battery Pack 32700 8S4P - BAKTH ZY-ED-3-E0359
BAKTH ZY-ED-3-E0359 (BAKTH code: 60002218A) is a high-performance 25.6V 20Ah lithium iron phosphate (LiFePO4) battery pack built with premium 32700 cells in 8S4P configuration. Designed for long-life energy storage, it delivers exceptional cycle life, robust safety and reliable power output for demanding applications.
Key Features
- Long Cycle Life: 4000+ charge/discharge cycles with 80% capacity retention - 4-5 times longer than lead-acid batteries.
- Superior Safety: Stable LiFePO4 chemistry with overcharge, over-discharge, short circuit and over-current protection.
- Smart BMS: Intelligent battery management with cell balancing, temperature monitoring and ultra-low self-discharge.
- High Energy Density: 25.6V 20Ah (512Wh) in a compact, lightweight and easy-to-install package.
- Customizable Design: Optional RS485/CAN communication, custom connectors, terminals and casing available.
Applications
Solar energy storage systems, RV and camper power, home energy storage, golf carts, electric vehicles, backup power and off-grid systems.
Contact us today for wholesale pricing and custom BAKTH LiFePO4 battery pack solutions.
